DOWSIL™ SE 9168 RTV One-Part Room-Temperature Moisture-Cure Silicone Adhesive/Sealant
DOWSIL™ SE 9168 RTV is a one-part room-temperature moisture-curing silicone adhesive/sealant designed primarily for electronics assembly. It cures through exposure to atmospheric moisture and does not require an oven. Its non-flowing paste consistency makes it suitable for component fixing and localized dispensing on circuit boards and modules. A key feature of SE 9168 RTV is its controlled silicone volatility, which helps reduce the potential for volatile silicone species to affect nearby sensitive electronic components. Dow’s current product page also lists a UL 94 V-0 flammability rating. At 50% relative humidity, tack-free time is approximately 6.5 minutes. After cure, the material has a Shore A hardness of approximately 44, elongation of approximately 363%, tensile strength of approximately 535 psi, and specific gravity of approximately 1.32 at 25°C. These properties provide both secure component fixing and flexible vibration damping.
Product Details
Product Features
One-Part Room-Temperature Cure:No mixing and no oven curing are required.
Fast Tack-Free Time:Approx. 6.5 minutes at 50% RH.
Non-Flowing Paste:Suitable for vertical surfaces and localized component fixing.
Controlled Silicone Volatility:Helps minimize the influence of volatile silicone species on surrounding electronic components.
Flame Resistance:UL 94 V-0 rating according to Dow’s current product page.
Flexible Vibration Damping:Approx. 363% elongation provides flexibility and stress relief.
Product Applications
PCB Component Fixing:Bonding and securing components on circuit boards.
Electronic Module Assembly:Fixing internal parts in electronic modules.
Vibration Damping:Reducing vibration transmission to fixed electronic components.
Housings & Assemblies:Elastic bonding within electronic housings and assemblies.
Flame-Resistant Electronics:Suitable for applications requiring additional flame resistance.
Room-Temperature Production:Useful in assembly processes where oven curing is undesirable or impractical.
| Item | DOWSIL™ SE 9168 RTV |
|---|---|
| Product Type | One-Part RTV Silicone Adhesive/Sealant |
| Brand | DOWSIL™ |
| Model | SE 9168 RTV |
| Chemistry | Silicone |
| Cure Mechanism | Moisture Cure |
| Cure Temperature | Room Temperature |
| Number of Parts | One Part |
| Appearance | Grey Paste |
| Flow | Non-Flowing |
| Specific Gravity | 1.32 at 25°C |
| Tack-Free Time | Approx. 6.5 min at 50% RH |
| Durometer | Shore A 44 |
| Tensile Strength | 535 psi, approx. 3.69 MPa |
| Elongation | 363% |
| Flammability | UL 94 V-0 |
| Water Solubility | Insoluble |
| Odor | Slight |
